MLFC®, Flame-Retardant Polyflex Insulated Wires

MLFC®, Flame-Retardant Polyflex Insulated Wires

MLFC®, Flame-Retardant Polyflex Insulated Wires, is suitable for cold temperature applications typically encountered in a diverse range of rail and transit applications. A voltage rating of 6600V is a typical application use for the MLFC, compatible with other cross-linked wiring solutions in the industry.

Characteristics

  • Compatible with flame-retardant cross-linked polyethylene compound
    Insulation is compatible with flame-retardant cross-linked polyethylene compound, which is specified in the Japanese Electrical Appliance and Material Safety Law.
  • Flame-retardant
    Same level or higher flame resistance then chloroprene rubber can be obtained, and no specified brominated flame retarder is contained.
  • Compliant with RoHS 2
    As indicated in 2002/95/EC “limitation of usage of specified hazardous chemical substances contained in electrical appliances and materials”.
  • High flexibility
    Combination of the flexibility-improved insulation and flexible stranded conductor has actualized excellent flexibility and wiring performance.
  • High tracking and corona resistance
    Superior tracking and corona resistance required for high-voltage wires are available up to 6600V.
  • High cold resistance
    Excellent cold resistance of min. permissible contractor temperature down to -50 degrees C. *For applications to be subjected to vibration, bending, or impact, please make sure to consult us in advance.
  • High varnish resistance
    Superior compatibility with coil varnish to be used at electrical work on motors. *It is necessary to consult us in advance since results of compatibility evaluation should depend on the type or condition of varnish treatment.
  • High heat resistance
    Excellent heat resistance up to 120 degrees C for 20,000-hour lifetime and up to 110 degrees C for 40,000-hour lifetime.
