NanoCore® Interconnect Plenum

NanoCore® Interconnect Micro Distribution offers 250 micron fiber optic strands in a loose tube design allowing for a higher fiber strand count in a very small overall diameter cable. Each fiber strand is color coded for easy identification. The cable is flexible and easy to handle and uses lightweight aramid yarns to enhance strength. NanoCore® Interconnect Micro Distribution cable is ideal for MPO (MTP™) style connectors where higher data rates are desired. Supported applications include Gigabit, 10 Gigabit and 40 Gigabit Ethernet. Made in USA. Proterial Cable America is proud to utilize Corning Optical Fiber as our standard optic fiber.

  • RoHS 3 compliant
  • All multimode, and singlemode cables (except OM1) utilize bend-insensitive optical fibers
  • 250 micron loose tube design allows for higher fiber strand counts in a smaller overall diameter cable
  • Ideal for MPO (MTP®) style connectors
  • Each fiber is color coded for easy identification
  • Flexible and easy to handle
  • Lightweight, flexible Aramid yarns enhance strength
  • Now available with a smaller outside diameter
  • When necessary, color-coded binders separate fiber strands into bundles of 12
Manufacturing Location
Manufactured in the USA
Cable RatingPlenum (UL) OFNP c(UL) OFNP FT6
Glass ConstructionGlass core with 125 micron cladding and 250 micron acrylate coating
Overall JacketFlame-retardant thermoplastic
Jacket Colors Aqua , Yellow
ApplicationsOM5 supports applications utilizing Short Wave Division Multiplexing (SWDM).
Custom OptionsEnhanced bend insensitive OS2
optical fiber available (ITU-T G.657.B3 & G.657.A2)
16 Fiber colors available
Colored threads are used to bundle fibers
OS2 optical fibers with enhanced bend-insensitive performance are available.
OM4+ and OM5 Available
Storage Temperature-40°C to +70°C (-40°F to +158°F)
Installation Temperature0° to 60°C (32° to 140°F)
Operation Temperature0° to 70°C (32° to 158°F)
FibersFibers / Fundle
/ Tube
Cable O.D.
inches / mm
50 UM
50 UM
8.3 UM
2-0.078” / 2.0mm62243-261539-2462239-2
2-0.118” / 3.0mm61507-261883-261538-2
4-0.118” / 3.0mm61507-461883-461538-4
12-0.078” / 2.0mm62243-1262244-1262239-12
12-0.118” / 3.0mm61507-1261883-1261538-12
12-0.150” / 3.8mm62374-1262375-1262371-12
12 DJ-0.189” / 4.8mm62449-1262450-1262460-12
16-0.118” / 3.0mm62685-1662686-1662689-16
16*8 X 20.118” / 3.0mm62694-1662695-1662698-16
24*12 X 20.118” / 3.0mm62243-2462244-2462239-24
24*12 X 20.150” / 3.8mm62374-2462375-2462371-24
24*12 X 20.177” / 4.5mm61507-2461883-2461538-24
24120.118” / 3.0mm
0.255” / 6.47mm
