The Cat6A Supra 10G-RD from Proterial Cable America delivers exceptional Category 6A performance with a significantly reduced outside diameter, allowing up to 26% more cable in the same space.
Utilizing Proterial Cable America’s advanced Noise Control Barrier™, the Supra 10G-RD supports 10 Gigabit Ethernet over distances up to 100 meters, meeting the ANSI/TIA-568.2-E standard, and is capable of supporting PoE applications up to 100 watts.
| Part Number | 30263-8 |
| Manufacturing Location | This product is produced and manufactured in the USA |
| Cable Rating | Plenum |
| Star Filler | Plenum-rated fluoropolymer |
| Shield | Proterial Proprietary Blocker Tape (MMAM Tape) |
| Jacket Material | Low-Smoke PVC |
| Jacket Colors | Black, Blue, Gray, Green, Orange, Red, Violet, White, and Yellow |
| Calculated Cable O.D. | 0.240" (6.096 mm) |
| Cable Weight | 33.1 lbs (15.0 kg) |
| Applications | • HDBase-T A & B • 10 Gigabit Ethernet (IEEE 802.3an) • 5 Gigabit Ethernet (IEEE 802.3bz) • 2.5 Gigabit Ethernet (IEEE 802.3bz) • Gigabit Ethernet (IEEE 802.3ab) • 100 Mbps Ethernet (IEEE 802.3u) • 1000 Mbps ATM • 622 Mbps ATM • 15W PoE (IEEE 802.3af) • 30W PoE+ (IEEE 802.3at) • 60W PoE++ (IEEE 802.3bt Type 3) • 100W PoE++ (IEEE 802.3bt Type 4) |
| Storage Temperature | -4°F to 194°F (-20°C to 90°C) |
| Installation Temperature | 32°F to 140°F (0°C to 60°C) |
| Operation Temperature | -4°F to 194°F (-20°C to 90°C) |
| Conductor Type | Solid Copper 23 AWG |
| Number of Conductors | 8 |
| Packaging | Reels REELEX |
Traditional Category 6A UTP cables control alien crosstalk by using large separator splines or by increasing the cable’s outer diameter to create physical distance between pairs. The NCB™ uses a specialized Proterial Special Blocker Tape (MMAM Tape) that acts as a continuous barrier around the cable core, attenuating alien crosstalk without adding bulk. The result is a Cat6A 10G cable that meets or exceeds the ANSI/TIA-568.2-E electrical performance requirements while being meaningfully slimmer and lighter, without compromising signal integrity.
The Supra 10G-RD supports Power over Ethernet up to 100W (IEEE 802.3bt Type 4, also called 4PPoE). It has been UL Tested (LP) for thermal performance under sustained high-power PoE loads to ensure safety. This makes it well-suited for powering demanding devices such as pan-tilt-zoom cameras, wireless access points, digital signage, and thin clients.
Yes. The Supra 10G-RD is a low-smoke Category 6A cable rated for plenum installation. It features a low-smoke PVC jacket and a plenum-rated fluoropolymer star filler, meeting the fire and smoke propagation requirements for use in air-handling spaces as defined by the National Electrical Code and NFPA 262. Always verify local code requirements before installation.
Let’s bring your project to life with the high-performance cables you need to drive innovation and build a better future.
Samples are available in 1m increments, up to 5m. Quotes are available for larger orders, available in 100m increments, subject to availability.
