Proterial Cable America (PCA) offers outdoor designs for Category 5e, 6 and 6A. These outdoor, or Outside Plant (OSP), cables are robust and designed to offer reliable performance regardless of the conditions in which they were installed. Tough polyethylene outer jackets with carbon black protect the cable core from water and the harsh sun. A gel-filled inner core prevents the migration of any water that may have breached the outer layers of protection. Whether used in lashed aerial, duct or underground conduits, these cables meet high technical performance reliability standards. They are designed to support applications such as Gigabit and 10 Gigabit Ethernet as well as deliver power to outdoor Power over Ethernet (PoE) devices.
| Part Number | 30145-8 |
| Manufacturing | This product is produced and manufactured in the USA |
| Cable Rating | Outdoor |
| Construction | Rugged Polyolefin Overall Jacket, Non-conductive, water blocking gel |
| Shield | None |
| Jacket Material | Plenum: Low-smoke, flame-retardant thermoplastic |
| Jacket Colors | Standard Black |
| Calculated Cable O.D. | 0.23” inches (5.8mm) |
| Cable Weight | 25.75 lbs/1000ft (11.68 kg/305m) |
| Applications | HDBase-T A & B (Cat 6) 5 Gigabit Ethernet (IEEE 802.3bz)(Cat 6) 2.5 Gigabit Ethernet (IEEE 802.3bz) Gigabit Ethernet (IEEE 802.3ab) 100 Mbps Ethernet (IEEE 802.3u) 1000 Mbps ATM 622 Mbps ATM 15W PoE (IEEE 802.3af) 30W PoE+ (IEEE 802.3at) 60W PoE++ (IEEE 802.3bt Type 3) 100W PoE++ (IEEE 802.3bt Type 4) |
| Storage Temperature | -40°C to +70°C (-40°F to +158°F) |
| Installation Temperature | -20°C to +70°C (-4°F to +158°F) |
| Operation Temperature | -40°C to +70°C (-40°F to +158°F) |
| Input Impedance | 100 ± 15 Ω (1.0 to 100 MHz) 100 ± 20 Ω (101 to 250 MHz) |
| Maximum Conductor Resistance | 330 pF/100 meters |
| Voltage Rating | 300 Volts |
| Maximum Delay Skew | 45 ns/30 meters |
| Nominal Velocity of Propagation (NVP) | 63% |
| Ampacity | Refer to catalog for chart |
| Gauge | 24 AWG |
| Conductor Type | Bare Copper |
| Number of Conductors | 8 (4-Pair) |
| Packaging | 1,000 ft reels Reverse sequential footage markings standard on each 1,000 foot package |
